| Specifikacija |
- PIANO: 41 keys with velocity sensitivity and aftertouch
BUTTON: 92 buttons with velocity sensitivity and aftertouch via Master Bar
- 120 bass buttons with velocity sensitivity
Standard and Free Bass mode
- Advanced T2L Engine
- 320 voices
- 45
- 14 Treble, 7 Bass/Chord, 7 Free Bass
- 9 Treble (16’,16’-,8’,8’-,8’+,4’,5’⅓, 2’⅔)
5 Bass (16’, 8’, 8-4’, 4’, 2’) with selectable lowest note
5 Chord (16’, 8’, 8-4’, 4’, 2’) with selectable lowest note
3 Free Bass (8’, 4’, 2’)
- Tone Wheel 1-2, Transistor (Farf, Vox), Pipe types with over 148 patches assignable to the registers
- 14 Treble, 7 Bass/Chord, 7 Free Bass
- More than 170 patches assignable to 14 Treble Registers, 159 patches assignable to 7 Bass/Chord registers / 7 Free Bass registers
23 Special HSC Sounds (Hyperreal Sound Cluster) for chord and bass section
- 14 Treble, 7 Bass/Chord, 7 Free Bass
- Over 170 Orchestra 2 / 18 Soloist / 42 Synth patches assignable to the Treble registers
- 14 Trebles
- 80 Drum set assignable to the 7 Bass/Chord registers, 7 Free Bass registers
Over 100 Drum instruments
- 7 Bass/Chord, 7 Free Bass
- Uploadable from USB memory and saveable on internal memory ( ~ 580 MB of free space available )
- 100 Banks of 6 Scenes each, providing 92400 stored registers in total
- Master Reverb/Delay/EQ
2 Multi Effects for each individual Part
Rotary, Vibrato/Chorus, Overdrive for Organ sounds
- • “Advanced Proportional Bellows Behavior” technology to control the resistance of the bellows by selected registers, number of keys pressed and individual note pitch.
• Independent resistance between push and pull of the bellows to balance the movement.
• “Adaptive Expression Interpolation” for smoother transition and fast bellow shaking.
• “Seamless Release” on Orchestral sounds at Bellows changes & inversion.
- • Musette detuning for each individual note: Off, 15 curve types Bellows Expression, Bellows Detune
• Continuous sound-attack shaping from Slow to Fast
• Bass & Chord Growl noise, Treble Growl noise (16'), Aging, Bellows direction
• Individual Reed Starts, Cassotto, Treble Valve-Off noise, Treble Key-On noise
• Bass & Chord Key-Off mechanical noise, Bass & Chord Key-On noise, Valve Air blow (Treble, Bass & Chord, Free bass), Bellows resonance.
- Accordion Type - Organ Type (Easy Mode)
Scenes (Advanced Mode)
- Adjustable from 415.4 to 466.1 Hz (step of 0.1 )
- 9 types
- Main Volume, Main Balance, DATA/ENTER, Reverb Level, Delay Level, FX-C1, FX-C2, 3 Chin Switches, Master Bar control, Master Bar switch, Touch Sensor, “G” Sensor
- • Bass & Chord Hold
• Treble Long Release
• Octave -1,0, +1
• 6 user assignable switches on last row of bass buttons
• Sound Edit: Orchestra, Orchestra2, Soloist, Synth
- A2DP for RX audio streaming and MIDI BLE 4.2
- Color LCD 2.4”, 320 x 240 dots
- YES
- Biamp and DSP: 112 W max @THD+N<0.1%
- 24V DC 5A DYS6150-2400500W
- Rechargeable Lithium-Ion battery: (4S2P 14,4 V, 6600 mAh) for over 9 hours autonomy
- OUTPUT jacks L/Mono (Treble), R/Mono (Bass): 1/4” phone type
PHONES jack: 1/4” phone type
MIDI (IN/OUT) sockets
USB MEMORY port: type A<>brUSB COMPUTER port: type B (for MIDI and DIGITAL AUDIO IN/OUT 16 bit, 48 KHz)
DC IN connector
- Stand By: < 0.4W
Maximum: 74W
"ErP" LEVEL VI for Echo efficiency on stand-by consumption
- 542 (W) x 408 (D) x 289 (H) mm
21-3/8 (W) x 16-1/16 (D) x 11-7/16 (H) inches
- 500 (W) x 381 (D) x 269 (H) mm
19-11/16 (W) x 15 (D) x 10-5/8 (H) inches
- 10.6 kg (excluding AC adaptor)
23 lbs 6 oz (excluding AC adaptor)
- 10.3 kg (excluding AC adaptor)
22 lbs 12 oz (excluding AC adaptor)
- • Multilingual Quick Guide
• DYS6150-2400500W AC adaptor
• Power cord (for connecting the AC adaptor)
• Rechargeable Lithium-Ion battery
• Reference caps for the bass buttons
• Reference buttons for the treble keyboard (only for FISA SUPREMA button type)
• Straps
• Accordion Cloth
• Soft accordion bag
• Elastic band for battery
|
