| Top Panel: |
| Display: |
1.8" color LCD display |
| Housing: |
Matte black powder coated steel chassis |
| Pedals: |
(2) die-cast aluminum pedals with titanium grey satin finish |
| Controls: |
360° navigation wheel with push-to-enter and hold function with RGB LED ring indicator |
| |
Instrument input gain control knob with real-time LED input level meter |
| |
Microphone input gain control knob with real-time LED input level meter |
| |
Main volume control knob with real-time LED output level meter |
| |
|
| Real Panel: |
| I/O: |
Combo XLR+1/4” (6.35 mm) balanced input (mono) |
| |
(2) 1/4” (6.35 mm) balanced inputs (stereo pair) |
| |
1/4" (6.35 mm) single or dual footswitch input (TS or TRS) |
| |
(2) 1/4” (6.35 mm) balanced outputs (stereo pair) |
| |
1/8” (3.5 mm) MIDI Input (5-Pin to 1/8” adapter included) |
| |
USB Type-B port |
| |
Power adapter input with power switch and cable restraint |
| |
|
| Power Specifications: |
| DC Power Input: |
9V DC, 500mA, Center-Negative, 2.1mm Barrel (adapter not included) |
| USB Power Input: |
Yes |
| Battery Power Type: |
4 x AA (Alkaline) (Included) |
| Est. Battery Life: |
Over 6 Hours (may vary based on conditions of use/battery brand) |
| |
|
| Looping Specifications: |
| Looper Modes: |
4 (Single, Multi, Song, Sync) |
| Looping Functions: |
Record, Overdub, Play, Stop, Undo/Redo, Clear Track, Clear All, Reverse, 1/2 Speed, Fade In/Out, Solo, Mute |
| Max # of Looper Tracks: |
2 |
| Max Loop Length: |
1.5 Hours |
| Max Overdub Layers Per Loop: |
Unlimited Layers |
| Max Overdub Time Per Loop: |
30 Minutes |
| Loop File Storage Format: |
.WAV (32-Bit PCM, 44.1 kHz) |
| Max # of Stored Loops: |
128 |
| Onboard Storage Time: |
Over 3 Hours |
| Onboard Storage Space: |
~4.1GB |
| |
|
| Other Features and Functionality: |
|
| External Pedal Assignment: |
Yes (for Single or Dual Footswitch) |
| USB Transfer Mode: |
Yes |
| USB Audio Interface Mode: |
Yes |
| Control from External MIDI Devices: |
Yes |
| MIDI Clock Sync: |
Receive |
| Audio Routing Customization: |
Stereo, Mono or Split (Loop/Dry) |
| |
|
| Audio Processing Specifications: |
|
| Processor Type: |
Custom single-core HeadRush(R) DSP |
| System Audio Bit Rate: |
32-Bit PCM |
| System Audio Sample Depth: |
44.1 kHz |
| A/D D/A Conversion: |
24-Bit |
| |
|
| USB Recording Specifications: |
| Bit Rate: |
24-Bit |
| Available Sample Depths: |
44.1 kHz |
| Input Channels: |
2 |
| Output Channels: |
2 |
| |
|
| USB Loop Import Specifications: |
| Supported File Types: |
Stereo .WAV |
| Supported Bit Rates: |
16-bit PCM, 24-bit PCM, 32-bit PCM, or 32-Bit Float |
| Supported Sample Rates: |
44.1 kHz |
| |
|
| Dimensions and Weight: |
| Pedal Dimensions (WXDXH): |
8.52” x 6.24” x 3” (21.64 x 15.85 x 7.62 cm) |
| Pedal Weight: |
3.75 lbs. (1.7 kg) |
| Box Dimensions (WXDXH): |
12” x 9.24” x 6.12” (30.48 x 23.47 x 15.55 cm) |
| Box Weight: |
5.51 lbs. (2.5 kg) |
