Type
Condenser Pressure Gradient
Capsule
TK67S Center Terminated Diaphragm
Tube Type
5654W (New Old Stock)
Transformer
Lundahl LL 1935
Polar Pattern
Cardioid
Frequency Range
20Hz - 20kHz
Sensitivity
17mV/Pa
THD at 1kHZ at 1Pa (Amplifier)
< 0.3%
Output Impedance
< 300 Ω
Maximum SPL (for 1% THD)
130 dB
S/N Ratio
87 dBA
Self Noise (Amplifier)
7 dBA
Dimensions/Size
200 mm L x 46 mm Dia
Weight
650 g
Current Draw from Mains
50 mA
Power Supply
M 902 PSU - 7 Pin Female XLR Input, 3 Pin Male XLR Output
Cable
M 803 - 7 Meter TELEFUNKEN Tube Microphone Cable, 7 Pin Male & Female XLRs
Shock Mount
M 703 - Shock Mount, M 782 - Stand Mount
Flight Case
ZC03 - Light Weight Carrying Case
